<LED MODEL>

(1) Check that the front cover is closed
(2) Turn ON the power switch while holding down the [GO] button.
(3) After all LEDs on the panel are lit, only the Status LED goes out.
(4) Release the [GO] button and check that all LEDs are off
(5) Press the [GO] button dependşng on the necessary number of times.
(If the [GO] button is pressed, the Status LED is lighted. If the [GO] button is released the LED is out.)

<LCD PANEL>

(1) Check that the front cover is closed
(2) Turn ON the power switch while holding down the [GO] button.
(3) The message “USERS MODE” is show on the LCD panel with the orange backlight.
(4) Release the [GO] button and chechk that the Data LED is off
(5) Press the [GO] button dependşng on the necessary number of times.
If the [GO] button is pressed, the Status LED is lighted. If the [GO] button is released the LED is out.)

Once 1) Test Sample Page
Twice 2) Print Font
Three times 3) 1push printing recovery mode
Four times 4) HEx Dump Mode
Five Times 1) Test Sample Page
Six times 5) Network Reset (APIPA: ON)
Seven times 1) Test sample Page
Eight times 6) Factory Reset
Nine times 1) Test Sample Page
Ten times 7) Settings reset
